CRC - High Yield Strength Steel
CRC-HS
Quantity
Cold rolled coil - high yield strength steel
JIS G3135: SPFC340-SPFC590
JIS G3135: SPFC490Y-SPFC980Y
Cold rolled coil - high yield strength steel
JFS A2001: JSC270H, JSC340P, JSC340W, JSC340H
JFS A2001: JSC390P, JSC390W, JSC440P
JFS A2001: JSC590Y, JSC780Y
high yield strength steel
mechanical properties - JIS G3135：
Grade - T.S.(≥Mpa)-Y.S.(≥Mpa)-EL.(0.6~1.0mm≥%)-EL.(1.0~2.3mm≥%)
SPFC340 -340- -175- -34- -35-
SPFC370 -370- -205- -32- -33-
SPFC390 -390- -235- -30- -31-
SPFC440 -440- -265- -26- -27-
SPFC490 -490- -295- -23- -24-
SPFC540 -540- -325- -20- -21-
SPFC590 -590- -355- -17- -18-
SPFC490Y -490- -225- -24- -25-
SPFC540Y -540- -245- -21- -22-
SPFC590Y -590- -265- -18- -19-
SPFC780Y -780- -365- -13- -14-
SPFC980Y -980- -490- -6- -7-
JIS G3135: SPFC340-SPFC590
JIS G3135: SPFC490Y-SPFC980Y
Cold rolled coil - high yield strength steel
JFS A2001: JSC270H, JSC340P, JSC340W, JSC340H
JFS A2001: JSC390P, JSC390W, JSC440P
JFS A2001: JSC590Y, JSC780Y
high yield strength steel
mechanical properties - JIS G3135：
Grade - T.S.(≥Mpa)-Y.S.(≥Mpa)-EL.(0.6~1.0mm≥%)-EL.(1.0~2.3mm≥%)
SPFC340 -340- -175- -34- -35-
SPFC370 -370- -205- -32- -33-
SPFC390 -390- -235- -30- -31-
SPFC440 -440- -265- -26- -27-
SPFC490 -490- -295- -23- -24-
SPFC540 -540- -325- -20- -21-
SPFC590 -590- -355- -17- -18-
SPFC490Y -490- -225- -24- -25-
SPFC540Y -540- -245- -21- -22-
SPFC590Y -590- -265- -18- -19-
SPFC780Y -780- -365- -13- -14-
SPFC980Y -980- -490- -6- -7-
